Hydraulic Butt Fusion Machine V315 90MM-315MM (3" IPS -10" IPS)

Hydraulic Butt Fusion Machine V315 90MM-315MM (3″ IPS -10″ IPS)

Categories Hydraulic Butt Fusion Machine
Brand RIYANG Butt Fusion Machine Manufacturer
Model V315
Certificate CE, ISO9001
Packing Material Plywood Box
MOQ 1set
Working Range in MM 90mm – 315mm
Working Range in Inch 3 – 10Inch
Working Pressure Range 0 – 80Bar
FOB port Shanghai
Terms of Payment L/C, Western Union, T/T, Paypal
Download DOC
Update Time 2021-07-08
Contact us
Category:

Detail Information

Hydraulic Butt Fusion Machine V315 90MM-315MM (3" IPS -10" IPS)

V315 is an on-site poly fusion machine suitable for welding plastic pipes and fittings made of HDPE, PP, PVDF, and other thermoplastics material.

The machine is used to butt weld pipe and fittings such as elbow, tees, wye, and flange necks without any additional equipment by simply adjusting the clamps and drag bar.
Product Details
WELDING RANGE O.D.
90MM - 315MM
PISTON AREA
20.02 cm²
POWER SUPPLY
*220V±10%, 50/60HZ
TEMPERATURE RANGE
MAX. 320ºC
HEATER POWER
3.0KW
PACKING DIMENSION
930*620*630 MM
TRIMMER POWER
1.5KW
630*600*730 MM
PUMP POWER
0.75KW
650*340*380 MM
WORKING PRESSURE RANGE
0 - 80 BAR
GROSS WEIGHT
241KGS

FEATURES

  Basic Frame
  Featured by
  - Oil seal kit, origins from Germany, make sure
  that the pressure performance stays in a more
  stable way.
  - 4sets quick coupling helps the operator
  to prepare the machine better before and
  after welding, and we use STUCCHI which
  from Italy ensures no hydraulic oil leakages
  when unplugging or plugin.
  - Using an integral shaft (top chromate treatment)
  instead of the assembled shaft, ensure the
  chassis strength to avoid the possible frame
  twist or deform when dragging the pipe with
  extreme parameters.
  Heating Plate
  Featured by
  - We use Dupont from the USA for coating the heating plate,
  which is the best in the industry. It's many stickers on
  an aluminum plate, more non-sticky to plastic pipes surface.
  The temperature deviation of different points on the heating
  plate is 2-3 degrees (small size machine) and 5-6 degrees
  (big size machine).
  Trimmer
  Featured by
  - Safety Switch, which guarantees the operators' security,
  even with power on, the trimmer will not be running
  if operators do not press the button.
  Support
  Featured by
  - Ergonomic design
  Hydraulic Power Station

  Featured by

  - Solid relays have a bigger load capacity and
  working in a more stable situation, which has
  a much longer life.
  - The circuit breaker works with an electricity
  leakage protection switch. Including the
  earth wires, there're 2 elements to activate
  the protection when electricity is leaking.
  - Non-fan motor (small size machines),
  waterproof, sand-proof, and dust-proof
  at a higher level. The motor provides
  sufficient/full power to provide support
  for hydraulic power.
